MODEL : T2000
2SA3
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 2000 Kg
Maximum lifting moment - 4.2 Ton.m
Recommended power - 8 KW
Hydraulic system - 20 L/Min
Hydraulic system pressure - 16 MPa
Tank capacity - 35 L
Installation space - 650 MM
Tank weight - 650 Kg
Rotation angle - 360 °
MODEL : T3200
3.2SA3
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 3200 Kg
Maximum lifting moment - 7 Ton.m
Recommended power - 14 KW
Hydraulic system - 25 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 60 L
Installation space - 750 MM
Tank weight - 1280 Kg
Rotation angle - 360 °
MODEL : T3200Z
3.2SA4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 3200 Kg
Maximum lifting moment - 7 Ton.m
Recommended power - 14 KW
Hydraulic system - 25 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 60 L
Installation space - 750 MM
Tank weight - 1350 Kg
Rotation angle - 360 °
MODEL : T4000
4SA3
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 4000 Kg
Maximum lifting moment - 8.4 Ton.m
Recommended power - 16 KW
Hydraulic system - 25 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 60 L
Installation space - 750 MM
Tank weight - 1300 Kg
Rotation angle - 360 °
MODEL : T5000
5SA3
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 5000 Kg
Maximum lifting moment - 12.5 Ton.m
Recommended power - 18 KW
Hydraulic system - 32 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 100 L
Installation space - 850 MM
Tank weight - 2100 Kg
Rotation angle - 360 °
MODEL : T5000 Z
5SA4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 5000Kg
Maximum lifting moment - 12.5 Ton.m
Recommended power - 18 KW
Hydraulic system - 32 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 100 L
Installation space - 850 MM
Tank weight - 2200 Kg
Rotation angle - 360 °
MODEL : T6300
6.3SA3
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 6300 Kg
Maximum lifting moment - 16 Ton.m
Recommended power - 22 KW
Hydraulic system - 40 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 100 L
Installation space - 900 MM
Tank weight - 2350 Kg
Rotation angle - 360 °
MODEL : T6300 Z
6.3SA4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 6300 Kg
Maximum lifting moment - 16 Ton.m
Recommended power - 22 KW
Hydraulic system - 40 L/Min
Hydraulic system pressure - 20 MPa
Tank capacity - 100 L
Installation space - 900 MM
Tank weight - 2500 Kg
Rotation angle - 360 °
MODEL : T8000
8SU4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 8000 Kg
Maximum lifting moment - 20 Ton.m
Recommended power - 27 KW
Hydraulic system - 55 L/Min
Hydraulic system pressure - 24 MPa
Tank capacity - 160 L
Installation space - 1200 MM
Tank weight - 3800 Kg
Rotation angle - 360 °
MODEL : T8000 Z
8SU5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 8000 Kg
Maximum lifting moment - 20 Ton.m
Recommended power - 27 KW
Hydraulic system - 55 L/Min
Hydraulic system pressure - 24 MPa
Tank capacity - 160 L
Installation space - 1200 MM
Tank weight - 4100 Kg
Rotation angle - 360 °
MODEL : T10000
10SU4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 10000 Kg
Maximum lifting moment - 25 Ton.m
Recommended power - 30 KW
Hydraulic system - 63 L/Min
Hydraulic system pressure - 25 MPa
Tank capacity - 160 L
Installation space - 1200 MM
Tank weight - 3890 Kg
Rotation angle - 360 °
MODEL : T10000 Z
10SU5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 10000 Kg
Maximum lifting moment - 25 Ton.m
Recommended power - 30 KW
Hydraulic system - 63 L/Min
Hydraulic system pressure - 25 MPa
Tank capacity - 160 L
Installation space - 1200 MM
Tank weight - 4200 Kg
Rotation angle - 360 °
MODEL : T12000
12SU4
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 12000 Kg
Maximum lifting moment - 30 Ton.m
Recommended power - 30 KW
Hydraulic system - 63 L/Min
Hydraulic system pressure - 26 MPa
Tank capacity - 160 L
Installation space - 1300 MM
Tank weight - 4250 Kg
Rotation angle - 360 °
MODEL : T12000 Z
12SU5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 12000 Kg
Maximum lifting moment - 30 Ton.m
Recommended power - 30 KW
Hydraulic system - 63 L/Min
Hydraulic system pressure - 26 MPa
Tank capacity - 160 L
Installation space - 1300 MM
Tank weight - 4550 Kg
Rotation angle - 360 °
MODEL: T14000
14SU5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 14000 Kg
Maximum lifting moment - 35 Ton.m
Recommended power - 40 KW
Hydraulic system - 80 L/Min
Hydraulic system pressure - 28 MPa
Tank capacity - 160 L
Installation space - 1350 MM
Tank weight - 5200 Kg
Rotation angle - 360 °
MODEL : T16000
16SA5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 16000 Kg
Maximum lifting moment - 50 Ton.m
Recommended power - 40 KW
Hydraulic system - 80 L/Min
Hydraulic system pressure - 28 MPa
Tank capacity - 240 L
Installation space - 1400 MM
Tank weight - 6000 Kg
Rotation angle - 360 °
MODEL : T20000
20SU5
TECHNICAL SPECIFICATIONS
Maximum lifting capacity - 20000 Kg
Maximum lifting moment - 51 Ton.m
Recommended power - 55 KW
Hydraulic system - 80+63 L/Min
Hydraulic system pressure - 28 MPa
Tank capacity - 240 L
Installation space - 1300 MM
Tank weight - 9800 Kg
Rotation angle - 360 °
